Ergon Living

https://www.celegon.it/en/products/ergon-living-line/ergon-living

ERGON® LIVING HARDWARE VERSIONS:
ERGON® LIVING  hardware is designed to meet every manufacturing need while fully respecting product quality:

The  ERGON® LIVING S40  system: the vertical rotation rod is inserted in the leaf, which must be hollow-core with a minimum thickness of 40 mm. Two technical manuals are available for this system to build the jamb next to the upright or to use a flat jamb.

The  ERGON® LIVING TE  system: the vertical rotation rod is inserted in the jamb and the leaf can be hollow- core, solid or glazed, with a minimum thickness of 35 mm. This system is available in the following versions:
-  ERGON® LIVING TE . for jamb with upright
- ERGON® LIVING TE Slim  for flat jamb

Every version of  ERGON® LIVING  hardware can accept the  Soft Opening  inspectable damper and each version is available with base, small and large arms in anodised black and silver finish. The weight of the leaf must not exceed 70 kg. The maximum dimensions in are: width 150 cm, height 300 cm.

ERGON® 生活硬件版本：
ERGON® LIVING 硬件旨在滿足廣泛的製造需求，同時充分尊重產品質量：

ERGON® LIVING S40 系統：垂直旋轉桿插入刀片中，刀片必須是空心的，最小厚度為 40 毫米。 該系統有兩本技術手冊，可用於在立柱旁邊建造門框或使用扁平門框。

ERGON® LIVING TE 系統：插入門框的垂直旋轉桿，葉片可以是空心的、實心的或釉面的，最小厚度為 35 毫米。 該系統有以下版本：
- ERGON® LIVING TE 用於立柱
- ERGON® LIVING TE 用於超薄平板門框

ERGON® LIVING 硬件的每個版本都接受軟打開檢查阻尼器，每個版本都提供黑色和銀色陽極氧化底座、臂和吊桿。 葉子的重量不得超過 70 公斤。 最大尺寸為：寬 150 厘米，高 300 厘米。
